Entry pointSKU 52302
DesignCAD 2025 2D Express
Everything needed to produce a dimensioned drawing, and nothing to learn around it.
Licence typeAdd to cart $99.99Electronic deliveryLicence key and download link are emailed within minutes of the payment clearing. Nothing ships.
30-day money-back guaranteeIf it does not do the job, tell us inside 30 days and we refund it — on a licence that has not been activated.
Keep the installerAdd the Extended Download Service at checkout and your installer stays available for two years instead of thirty days.
Own an earlier DesignCAD? An upgrade costs less than a new licence. Check your upgrade price →
Recommended with this purchase
Everything needed to produce a dimensioned drawing, and nothing to learn around it.
DesignCAD™ is available in 2D and 2D/3D versions. DesignCAD™ 2D Express offers an intuitive interface and hundreds of 2D drafting and design tools, while DesignCAD™ 3D Max is also great for beginners, it is powerful enough to create high-quality designs, simple renders, and animations.
In DesignCAD 2D Express
- Ribbon
- 4K Screen Support
- IMPROVED: Performance optimized for 7 x faster redraw speed
- Updater
- 2D Draw Mode
- Find & Replace
- Selection Tool with smart object selection based on direction
- Batch File Converter
Every edition includes a full year of maintenance and support. What changes between them is how far the toolset goes — compare every edition row by row →
Key features
Smart MenusDesignCAD™ offers smart menus that are initially presented with a shortened list of available menu commands to help reduce screen clutter.
Pre-defined ViewsEasily switch between nine pre-set views—such as Front, Top, and Isometric—to adjust perspectives and improve visibility while working on designs. Pre-defined views in DesignCAD™ 3D Max
Selection ToolSelecting objects is determined by the direction of the selection window.
4K SupportOptimized for high-resolution displays, ensuring sharper visuals and improved readability on 4K screens for a more precise design experience.
Easy to Use 2D Drafting & DesignIntuitive yet sophisticated editing tools, advanced geometric construction capabilities, customizable keyboard shortcuts, and comprehensive layer management make 2D drafting effortless.
LayersDesignCAD™ utilizes layers that can be independently switched on and off for better visibility of the drawing.
Group Editor in Info BoxView the internal structure of a group and any subgroups, and reorganize contents without exploding it. Group editing options include: Move highlighted group members or entire subgroups to a different layer.
Drawing CompareSelect two DesignCAD™ drawings or BMP images, and the Drawing Compare feature will perform a visual comparison of the two.
Added Flexibility When Sharing Your WorkPrint Section: Print only a specified region of the drawing for focused output. Print Scale Options: Choose from a standard set of print scale options or create custom scales tailored to your needs.
- ODA 25.7 supportNewer DWG and DXF read and written.
- SketchUp 2024 supportCurrent SKP files import.
- Basic shapesA quicker route to the primitives most drawings start from.
- Points on Path toolPlace points along any path.
- DesignCAD UpdaterPatches arrive without a reinstall.
- Improved redraw performanceLarge drawings pan and zoom better.
Release2025
Edition2D Express
PlatformWindows
DeliveryDownload (ESD)
LicencePerpetual
InterfaceEN / DE
Support12 months included
Operating systemWindows 11 / 10
Memory4 GB minimum
GraphicsOpenGL capable GPU
DiskSee the spec sheet
Full requirements, supported file formats and licence activation details are on the DesignCAD support page.
